24V 100Ah Deep Cycle LiFePO4 Battery
Vcell Power, as a China-based supplier, delivers the24V 100Ah Deep Cycle LiFePO4 Battery, offering high-efficiency stable power with advanced safety design and long cycle performance. Backed by reliable IEC, UN38.3, CE, and ROHS certifications and global export experience, VCELL POWER ensures consistent quality for off-grid systems, marine use, and electric vehicle power supply needs.
Send Inquiry
Product Description
Vcell Power from China focus on 24V 100Ah Deep Cycle LiFePO4 Battery delivering a high-reliability lithium energy solution designed for deep cycle storage, marine systems, and electric mobility applications.
Parameters
| Battery Type | LiFePO4 Battery |
| Model | VP-LF24-200 |
| Nominal Voltage | 24V |
| Nominal Capacity | 100Ah |
| Charge Cut-Off Voltage | 29.2±0.2V |
| Discharge Cut-Off Voltage | 20.0±0.2V |
| Max Charge Current: | 100.0A |
| Max Continuous Discharge Current | 100.0A |
| Peak Discharge Current | 200.0A(1-3S) |
| Charge Temperature | 0~45℃ |
| Discharge Temperature | -20~65℃ |
| Storage Temperature | -20°C~50°C |
| Design Life | ≥10 Years |
| Cycle Life | ≥4000 @100% DOD0.5C Charge/Discharge |
| Dimension | 522*238*218*220mm |
| Weight | Approx 21.0Kg |
| Communication | M8 |
| IP Level | IP55 |
What makes 24V deep cycle lithium technology a stable power foundation for industrial energy systems?
High Energy Density & Deep Cycle Capability
The Battery is built with high-quality lithium iron phosphate cells, providing stable 24V output. Unlike traditional lead-acid batteries that limit discharge to 50%, this system supports deep discharge up to 100% DOD without damaging cycle life.
The Battery ensures consistent voltage output even under high-load conditions, making it ideal for continuous-duty applications such as logistics vehicles, RV systems, and off-grid solar storage.
Built-in BMS Protection for System Safety
VCELL POWER integrates an intelligent Battery Management System to protect:
This ensures stable operation of the 24V 100Ah Deep Cycle LiFePO4 Battery in vibration-heavy and high-demand environments such as marine systems and industrial fleets.
Application-Driven Feature Deployment
This battery is engineered for multi-scenario deployment:
The Battery supports long runtime with stable current output, ensuring uninterrupted energy delivery in mission-critical environments.
High Usable Capacity Reduces Oversizing Requirements
Unlike lead-acid batteries that can only safely discharge about 50%, the 24V 100Ah Deep Cycle LiFePO4 Battery supports up to 100% depth of discharge.
This means:
For RV, marine, and off-grid solar systems, this improves both design flexibility and cost efficiency.
Stable Performance Reduces System Failure Risk
VCELL POWER integrates strict cell matching, automated sorting, and aging tests to ensure consistency in every Battery.
This reduces:
For industrial buyers, system reliability is directly linked to operational revenue continuity.
Certifications & Global Trust
VCELL POWER products are certified under:
IEC, UN38.3, UL, CE, ROHS, KC, CB, ISO9001, MSDS, REACH, DG Cert, BIS
Service Support System
Pre-Sales Support
In-Sales Support
After-Sales Support
The Vcell Power 24V 100Ah Deep Cycle LiFePO4 Battery is designed for long-term energy reliability, combining safety, durability, and cost efficiency for global industrial and renewable energy applications. With strong manufacturing capability and strict quality systems, VCELL POWER ensures stable supply and consistent performance for every deployment.
